SMD 5050 Flexible RGBW RGB LED Rope Light Spool Waterproof With UL

SMD 5050 Flexible RGBW RGB LED Rope Light Spool Waterproof With UL

Products - LED Neon Lights
  • Highlight

    led rope light

  • Part No
    TL-SW10CA/B
  • LED Qty/m
    108pcs
  • LED
    SMD5050
  • Materials
    Silicone
  • IP Grade
    IP67
  • Color
    RGB RGBW
  • Voltage
    DC12V/24V
  • Performance
    Stable Reliability,UV And Yellowish Resistant
  • Cut Length
    28mm/56mm
  • Certification
    UL CE ROSH
  • Place of Origin
    Shenzhen,China
  • Brand Name
    TL
  • Certification
    CE,ROSH,UL
  • Model Number
    TL-SW10CA/B
  • Document
    Product Brochure PDF
  • Minimum Order Quantity
    1pcs
  • Price
    Negotiable
  • Packaging Details
    Carton
  • Delivery Time
    7-15 workdays
  • Payment Terms
    T/T
  • Supply Ability
    5000m/day

SMD 5050 Flexible RGBW RGB LED Rope Light Spool Waterproof With UL

  • SMD 5050 Flexible RGBW RGB LED Rope Light Spool Waterproof With UL
  • SMD 5050 Flexible RGBW RGB LED Rope Light Spool Waterproof With UL
  • SMD 5050 Flexible RGBW RGB LED Rope Light Spool Waterproof With UL
Get Price Contact Now

SMD 5050 waterproof Led flexible RGB RGBW neon strip light with UL

Application

  • Can be Widely used in building outline decoration lighting, KTV decoration lighting, Car decoration lighting,

          urban lighting and others decoration lighting​.



Product description

  •  Product standard length: 5 meters(16.4ft).
  •  Product can be fixed in the rugged place (smooth surface and bendable).
  •  Beam angle: 150°.
  •  Input voltage: 12VDC/24VDC.
  •  Excellent lumen maintenance (3oz FPC).
  •  12VDC product: maximum length 5 meters (16.4ft).
  •  24VDC product: maximum length 10 meters (32.8ft).
  •  Flexible cutting (the cut mouth sealed by silicone glue).
  •  IP68.
  •  Stable reliability and anti-UV.​



LED Type SMD-5050
Voltage 12V/24V
Color RGB/W/R/G/B/Y/A
Refresh Frequency 800 KB
Application Outdoor decoration light
IP rank IP20/IP65/IP68/IP67
IC Model P943
Wire 99.99% pure gold wire
Warranty 3 Years

SMD 5050 Flexible RGBW RGB LED Rope Light Spool Waterproof With UL 0

SMD 5050 Flexible RGBW RGB LED Rope Light Spool Waterproof With UL 1

Technical data

    Part No light color  light wavelength (nm) light angle (°) lumens (lm/m) light efficiency (lm/W) voltage (DC/V) power (W/M)

TL-SW10CA/B

 R 617 120 55.25 12.79 12/24

17.28
G 515 120 136.79 21.11 12/24
B 462 120 26.19 4.042 12/24


    ① Tolerance range for optical and electrical data: ±15 %.

② All value @ ta=25℃.

③ Voltage tolerance range of the power supply: ±5 %.



Maximum length①

10/15 meters

                                                          (32.8/49.2ft)
Ambient temperature range -25 ~ +50 °C
The temperature of module top 65 °C
Storage temperature range -40 ~ +70 °C
Certification CE/UL/ RoHS





 Product 2D drawing



  • 12VDC/24VDC product interior drawing


SMD 5050 Flexible RGBW RGB LED Rope Light Spool Waterproof With UL 2



  • Product installation schematic diagram



SMD 5050 Flexible RGBW RGB LED Rope Light Spool Waterproof With UL 3





Product sectional drawing




SMD 5050 Flexible RGBW RGB LED Rope Light Spool Waterproof With UL 4







Installation


SMD 5050 Flexible RGBW RGB LED Rope Light Spool Waterproof With UL 5





Benging direction

SMD 5050 Flexible RGBW RGB LED Rope Light Spool Waterproof With UL 6




Light distribution

SMD 5050 Flexible RGBW RGB LED Rope Light Spool Waterproof With UL 7



Packaging information





Product name

Productd

dimension

(L*W*H)

Carton dimension

(mm/inch)



Total length/carton

Gross
weight (kg)



RCC0GX06A/B(2835)

 5m*10mm*17mm (16.4ft*0.39"*0.67")

390*390*325

(15.4"*15.4"*12.8")



60m (195ft)



15.5
