V-2 Flame Resistant Outdoor LED Rope Lighting 6mm Wide Stable Reliability
-
Highlight
led rope light
-
Light Source2835 SMD
-
Input Voltage12V
-
Beam Angle150°
-
CRI (Ra>)85
-
IP RatingIP68
-
ColorWhite/red/green/blue/yellow /pink/purple
-
Dimension6*12mm
-
Lamp BodySilicone
-
ApplicationIndoor/Outdoor Decoration
-
CertificationUL CE ROSH
-
Place of OriginShenzhen,China
-
Brand NameTL
-
CertificationCE,ROSH,UL
-
Model NumberTL-SW06A/B
-
Document
-
Minimum Order Quantity1pcs
-
PriceNegotiable
-
Packaging DetailsCarton
-
Delivery Time7-15 workdays
-
Payment TermsT/T
-
Supply Ability5000m/day
V-2 Flame Resistant Outdoor LED Rope Lighting 6mm Wide Stable Reliability
Ip68 Waterproof 12V Led Neon Light Silicone Neon Flex Rope 6mm Wide with CE UL
Product Description
-
In order to further upgrade products, improve product quality and product usage lifetime, our engineers devoted themselves to research, Our company decided to produce a new generation of silicone neon strips, Compared with the traditional PVC material, Silicone neon lights more soft, environmental , high temperature resistance, waterproof grade IP68, for indoor and outdoor decorative lighting. Because of soft texture, It can be any bent for 180 degrees, So it can make any shapes and sign easily. The advantages of silicone neon strips are self-evident.
Product features
- Dot-free linear neon-like illumination;
- Fabricated with Eco-friendly, UV-resistant silicone material;
- V-2 flame resistance;
- Flexible PCB with 2835 SMD LED technology;
- 25mm cutting mark by each, much flexible on different length request;
- Small size L6XW12mm, economical;
- CE RoH, cULus Listed..
-
Beam angle: 120°.
-
Input voltage: 12VDC/24VDC.
-
Excellent lumen maintenance (3oz FPC).
-
IP68.
-
table reliability and anti-UV.
Application data
| Maximum length① |
10/15 meters (32.8/49.2ft) |
| Ambient temperature range | -25 ~ +50 °C |
| The temperature of module top | 65 °C |
| Storage temperature range | -40 ~ +70 °C |
| Certification | CE/UL/ RoHS |
Installation
U-type PC accessory to fix
Technical data
| Product Name | Nominal voltage③ | Color temperature or Wavelength①② | CRI①② |
Typ. Flux/meter(3.28ft) ①② |
Typ. Power/meter(3.28ft)①② |
| TL-SW06A/B(2835) | 12/24 VDC | 2700-5500 K | >75 | 850~1100 lm | 12 W |
| TL-SR06A/B(2835) | 12/24 VDC | 620-625 nm | Red | 300~350 lm | 12 W |
| TL-SG06A/B(2835) | 12/24 VDC | 520-528 nm | Green | 210~230 lm | 12 W |
| TL-SB06A/B(2835) | 12/24 VDC | 465-470 nm | Blue | 1100~1010 lm | 12 W |
| TL-SY06A/B(2835) | 12/24 VDC | 590-596 nm | Yellow | 300~310 lm |
12 W |
① Tolerance range for optical and electrical data: ±15 %.
② All value @ ta=25℃.
③ Voltage tolerance range of the power supply: ±5 %.
Product 2D drawing
- 12VDC/24VDC product interior drawing
3 LEDs cut-able
6 LEDs cut-able
- Product installation schematic diagram
Product sectional drawing
Product application
Product ⇒ Fix letter groove ⇒ Clip product ⇒ Actual result
Connect two products
Product ⇒ Cut the product based ⇒ Solder the wire ⇒ Actual result
on application requirement “+/+”, “-/-“
Benging direction
The maximum bending angle 360°The minimum bending radius: 15mm (0.59")
Light distribution
Packaging information
|
Product name |
Product dimension (L*W*H) |
Carton dimension (mm/inch) |
Total length/carton |
Gross weight (kg) |
|
RCC0GX06A/B(2835) |
5m*6mm*12mm (16.4ft*0.32"*0.47") | 520*370*260 (20.5"*14.5"*10.2") |
200m (656ft) |
20 |
