PIR Solar Panel LED Street Lights Timer Control 6-7 Meters Installation Height
-
Highlight
commercial solar pole lights
,solar powered road lights
-
LED Lamp40W
-
Solar Panel50W
-
BatteryLi-ion Battery 3.7V 251WH
-
MaterialAluminium Alloy
-
Charge Time(by Sun)8-10hours (with Enough Strong Shine)
-
Discharge Time10-12 Hours Per Night 5-7rainy Days
-
Installation Height6-7meters
-
Suggestion Distance25-30meters
-
Place of OriginChina
-
Brand NameCO-SHINE
-
CertificationCE RoHS
-
Model NumberModel: DM-840
-
Document
-
Minimum Order Quantity20
-
Packaging DetailsBox 1：1140*390*120 mm（lamp body） Box 2 ：350*290*220mm(Supportor+Accessories）
-
Delivery Time3-5 days
-
Payment TermsL/C, T/T, Western Union, MoneyGram
PIR Solar Panel LED Street Lights Timer Control 6-7 Meters Installation Height
PIR Motion Sensor And Timer Control Solar LED Street Lighting 40W With High Efficiency Solar Panel
Product features
- die casting aluminum alloy material for the profiles, with a good stereotype effect. prevent solar panels from sliding.
- High quality 【Bridgelux 】LED chip, 130-140lm/w, high brightness
- efficiently imported silicon high efficiency special surface treatment
- independent plastic battery box, overall waterproof, heat insulation and dustproof
- Openable for controller replacement and openable for battery replacement
- special aluminum material, with a good heat conduction
- Time control and PIR sensor mode
Specification
| Solar street light 40W | Model: DM-840 | ||||
| Main Lamps material | Aluminium Alloy | ||||
| Solar panel | Max Power | 50W | |||
| Battery | li-ion battery | 3.7V 251WH | |||
| LiFePO4 battery | 3.2V 224WH | ||||
| LED | Led chip brand | Bridgelux from USA with high brightness | |||
| Lumen(LM) | 4400 -4800LM equal to15W | ||||
| CCT (k) | 6000-7000k | ||||
| Life Time | 50000 hours | ||||
| Lighting Viewing Angle | 140°×70° | ||||
| Working TEMP( ℃ ) | -20°~+60° | ||||
| Working Mode | 1. Time Control Mode , 2.Sensoring Mode , 3.Time Control + Sensoring Mode (Switched by smart remote control) | ||||
| Charge time(by sun): | 8-10hours (with enough strong shine) | ||||
| Discharge time | 10-12 hours per night 5-7rainy days | ||||
| Certificate | CE/ROHS/IP66 | ||||
| Packing | Product size | 1031*315*206 mm | |||
| Packing size | Box 1:1140*390*120 mm(lamp body) Box 2 :350*290*220mm(Supportor+Accessories) |
||||
| Net weight | 12kg | ||||
| Gross weight | 14kg | ||||
| Packing way | 1sets/2carton | ||||
| Packs Containers | 20ft container | 435pcs | |||
| 40gp container | 839pcs | ||||
| Installation height | 6-7meters | Suggestion distance | 25-30meters | ||
Details
Application:
1.Major Roadways.
2.Residential Streets.
3.Pedestrian Walkways.
4.Parking Lots.
5.Expressway.
6.Docks and Piers.
7.Remote and Rural Locations.
8.High crime areas.
9.square sport grounds.
10.industrial plants and other advertising lights
Quality Control
Professional salt spray test:
The whole housing has been tested for 72 hours of salt spray test. It can be protected against rust for three years.
Other tests:
100% of the light will be tested and keep lighting for 24 hours to test its quality reliability , and we will also test its temperature after 24 hours’ lighting.
Then after it is cool we again test 100% of the light to see if it still work well . Each light should pass all these QC procedures before shipping to customer
or by sea which takes about one month to arrive , depending on your actual requirements.
1. For all your inquires about us or our products, we will reply you in detail within 24 hours;
2. We own well-tranied and passional sales & after- sale services who can speak fluent Engligh language;
3. We offer OEM services. Can print your own logo on product , can customize the retail box packing and other things.
4. We have very experienced R&D engineers and we have strong ability to do ODM projects.
Our products are sold all over the world, you can rest assured.
