Waterproof Recessed Slim Panel Led Downlight 9W COB LED Source Input 85 - 265V
-
Highlight
led slim downlights
,flat led ceiling light
-
Input Voltage(v)AC85-265V
-
Color Temperature(cct)Cool White,2700-6500K,Warm White,Pure White,3000K4000K6000K
-
Light SourceLED
-
Cri (ra>)80,85
-
Warranty(years)3
-
DescriptionDown Light
-
CertificationCE,RoHS,EMC
-
Working Temperature(℃)-20 - 45
-
Place of OriginChina
-
Brand NameAina Lighting
-
CertificationCE, ROHS
-
Model NumberKoala 9
-
Document
-
Minimum Order Quantity10
-
Packaging DetailsCarton
-
Delivery Time7 days for samples
-
Payment TermsL/C, T/T, Western Union
-
Supply Ability10000 per day
Waterproof Recessed Slim Panel Led Downlight 9W COB LED Source Input 85 - 265V
Koala Series Waterproof Recessed led Down Light 9W COB LED Source Input 85-265V
Features
Soft lighting, high transmittance, Uniform luminescence
No coating falling off, color changing, anti-backflow
Plastic housing,V-2 flame rating.
Drive on board design.
Triac dimmable(A) and Tri-color(B) available.
Uniform light, without LGP, no yellowing risk.
3000K 4000K 6000K for option.
Warranty: 3years. IP44 front only. 110°beam angle.
- 1. White inner box or color box,Brown Master carton .
2. OEM package available - Port
- Shanghai
- Lead Time :
-
Quantity(Pieces) 1 - 1000 >1000 Est. Time(days) 45 To be negotiated
Application
Shopping mall, Super-market, Hotel, Office, Path way, Stations, School, Library, Living room
Specification
| Model No. | Wattage |
Lumens(±10%) Lm |
Input Voltage | CCT | CRI |
Dimensions mm |
Cutout mm |
| AN-Koala-9W-92/R8TW | 9W | 810-1000 |
220-240V ~50-60Hz |
3000K 4000K 5700K CCT Selectable |
Ra80 | Φ104*H30 | Φ92 |
| Model No. | Wattage |
Lumens(±10%) Lm |
Input Voltage | CCT | CRI |
Dimensions mm |
Cutout mm |
| AN204-6W-105x105/R8TW | 6W | 480-510 | 220-240V~50-60Hz |
3000K 4000K 6000K CCT Selectable |
Ra80 | 120*120*35 | 105*105 |
| AN204-12W-155x155/R8TW | 12W | 960-1020 | 170*170*38 | 155*155 | |||
| AN204-18W-205x205/R8TW | 18W | 1440-1530 | 220*220*45 | 205*205 |
| Model No. | Wattage |
Lumens(±10%) Lm |
Input Voltage | CCT | CRI |
Dimensions mm |
Cutout Mm |
| AN203-6W-100/R8TW | 6W | 480-510 | 220-240V~50-60Hz |
3000K 4000K 6000K CCT Selectable |
Ra80 | Φ113*35 | Φ90-100 |
| AN203-12W-150/R8TW | 12W | 960-1020 | Φ174*38 | Φ145-155 | |||
| AN203-18W-205/R8TW | 18W | 1440-1530 | Φ244*38 | Φ198-210 | |||
| AN203-20W-220/R8TW | 20W | 1600-1700 | Φ265*41 | Φ215-230 |
About us
Aina-4 Technologies (Shanghai) Co., Ltd. is a private limited company registered in Shanghai, China. It specializes in the R&D, design, manufacture, and marketing of light emitting sources and lighting fixtures. It is an enterprise formed by four (4) pioneer lighting companies, putting their resources together to produce products and services that create sustainability not only for the environment, but also for the economies and societies that the company grows with.
Aina-4 products reflect the business philosophy of raising customer expectations and giving them freedom of personal expression through best quality design, materials, and manufacturing processes, at the same time making sure that it leaves a positive impact on all stakeholders socially, economically, and ecologically.
FAQ
Q1: Are you factory?
A1: YES. Welcome to visit our company and factory.
Q2: What is the warranty?
A2: At least 3 years warranty.
Q3: What is the shipping way?
A3: DHL, UPS, TNT, EMS, FedEx. By sea.
Q4: What is the payment terms?
A4: L/C.T/T.
