Color Changing Led Slim Round Panel Downlight Plastic Housing For Kitchen / Live Room
-
Highlight
led ceiling downlights
-
Color Temperature(cct)Cool White,2700-6500K,Warm White,Pure White,3000K4000K6000K
-
Input Voltage(v)AC85-265V
-
Working Temperature(℃)-20 - 45
-
Cri (ra>)80,85
-
Warranty(years)3
-
Light SourceLED
-
DescriptionDown Light
-
CertificationCE,RoHS,EMC
-
Place of OriginChina
-
Brand NameAina Lighting
-
CertificationCE, ROHS
-
Model NumberAN204
-
Document
-
Minimum Order Quantity10
-
Packaging DetailsCarton
-
Delivery Time7 days for samples
-
Payment TermsL/C, T/T, Western Union
-
Supply Ability10000 per day
Color Changing Led Slim Round Panel Downlight Plastic Housing For Kitchen / Live Room
204 version LED Panel Light With Round Outlook Flat Panel for Kitchen and Live Room
Application
Shopping mall, Super-market, Hotel, Office, Path way, Stations, School, Library, Living room
Features
Soft lighting, high transmittance, Uniform luminescence
No coating falling off, color changing, anti-backflow
Plastic housing,V-2 flame rating.
Drive on board design.
Triac dimmable(A) and Tri-color(B) available.
Uniform light, without LGP, no yellowing risk.
3000K 4000K 6000K for option.
Warranty: 3years. IP44 front only. 110°beam angle.
Specification
| Model No. | Wattage |
Lumens(±10%) Lm |
Input Voltage | CCT | CRI |
Dimensions mm |
Cutout mm |
| AN204-6W-105x105/R8TW | 6W | 480-510 | 220-240V~50-60Hz |
3000K 4000K 6000K CCT Selectable |
Ra80 | 120*120*35 | 105*105 |
| AN204-12W-155x155/R8TW | 12W | 960-1020 | 170*170*38 | 155*155 | |||
| AN204-18W-205x205/R8TW | 18W | 1440-1530 | 220*220*45 | 205*205 |
| Model No. | Wattage |
Lumens(±10%) Lm |
Input Voltage | CCT | CRI |
Dimensions mm |
Cutout Mm |
| AN203-6W-100/R8TW | 6W | 480-510 | 220-240V~50-60Hz |
3000K 4000K 6000K CCT Selectable |
Ra80 | Φ113*35 | Φ90-100 |
| AN203-12W-150/R8TW | 12W | 960-1020 | Φ174*38 | Φ145-155 | |||
| AN203-18W-205/R8TW | 18W | 1440-1530 | Φ244*38 | Φ198-210 | |||
| AN203-20W-220/R8TW | 20W | 1600-1700 | Φ265*41 | Φ215-230 |
About us
Aina-4 Technologies (Shanghai) Co., Ltd. is a private limited company registered in Shanghai, China. It specializes in the R&D, design, manufacture, and marketing of light emitting sources and lighting fixtures. It is an enterprise formed by four (4) pioneer lighting companies, putting their resources together to produce products and services that create sustainability not only for the environment, but also for the economies and societies that the company grows with.
Aina-4 products reflect the business philosophy of raising customer expectations and giving them freedom of personal expression through best quality design, materials, and manufacturing processes, at the same time making sure that it leaves a positive impact on all stakeholders socially, economically, and ecologically.
FAQ
Q1: Are you factory?
A1: YES. Welcome to visit our company and factory.
Q2: What is the warranty?
A2: At least 3 years warranty.
Q3: What is the shipping way?
A3: DHL, UPS, TNT, EMS, FedEx. By sea.
Q4: What is the payment terms?
A4: L/C.T/T.
Q5: Can we design customer packaing?
YES. We can design customer's own packing
Q6: Can we add our logo on super bright led panel light?
A6: YES. You can add your logo on super bright led panel light.
Q7: Can we customize super bright led panel light?
A7: YES. OEM&ODM.
Our products are sold all over the world, you can rest assured.
