IP20 Indoor LED Strip Lights 5050 RGBW Per Meter
Our Product Introduction
for more products please visit us on solarpanelstreetlight.com
Basic Information
Place of Origin:
Shenzhen China
Brand Name:
TL
Certification:
ETL CE RoHS UL
Model Number:
TL-FW50-IN84RGBW-CV80-12-24V_Blue
Minimum Order Quantity:
1000M
Price:
Negotiable
Packaging Details:
Carton box
Delivery Time:
2-3 weeks
Payment Terms:
T/T
Supply Ability:
30000M per month
Product Specification
LED SMD:
5050
Color:
Blue
Luminous Efficiency:
20lm/w
Voltage:
24VDC
Wattage:
8W/M
CRI:
80
Working Temperature(℃):
-20~60℃
Pcb Color:
12MM White Color
Highlight:
exterior led tape light
,external led strip lights
Our Product Introduction
for more products please visit us on solarpanelstreetlight.com
Product Description
84LEDs Per Meter IP20 RGBW Indoor Special LED Strips 500 to 600lm Per Red color
SMD5050 RGBW
High luminous Efficiency 20lm/w
84LEDs per meter, 6LEDs per cutting
24DCV
Warranty 3 years
Beam angle 120°
2 layer PCB/1+2OZ copper 12mm width
CRI≥80, life time 50000h
R: 620-630nm, G: 515-525nm, B: 460-470nm
1, Features
High quality flexible PCB strip with ETL UL RoHS and CE certified
Use 2835 SMD LED as light source with high brightness and large vier angle
Environment friendly, no UV, noinfrared, no radiation
Use high qualily LED
6pce LED/cutting section
| Item | Unit | Data | Item | Unit | Data | |
| LED type | / | SMD 5050 | LED quantity/m | PCS | 84 | |
| LED brand | / | Epistar or equivalent Sanan | LED power dissipation/m | W | 8.1 | |
| Beam angle | 2θ1/2 | 120 | Strip power dissipation/m | W | 9.53 | |
| PCB type | type | 2 layer PCB/1+oz copper 12mm | Luminous flux±10% | lm/m | 435-525 | |
| Length | M | 5 | Efficacy | lm/w | 20 | |
| Protection degree | IP | IP20 | Operating Voltage | VDC | 24 | |
| Tape | / | 3M 9495 200MP | Operating current/m | A | 0.7 | |
| Color | / | WW/NW/CW | Ta(ambient temperature) | ℃ | -20℃~60℃ | |
| CRI | Ra | ≥80 | Tc(surface temperature) | ℃ | Max. 67 | |
| CCT | Red |
620-630nm |
- | Heatsink | c㎡/m | 807 |
| Green | 515-525nm | - | Warranty period | year | 3 | |
| Blue | 460-470nm | - | Life time | H |
50000 |
|
| - |
- |
- | ||||
2, Layout
3, Outline drawing
4, Connection Diagram
